Laptops

Product views 1. Microphones
2. Camera shutter
3. Camera
4. IR Camera
5. 16″ display
6. HDMI port
7. USB 3.2 Gen 1 port with power-off charging
8. USB Type-C port with DC-in
9. USB Type-C port with DC-in
10. Touchpad
11. Power button
12. Keyboard
13. Power indicator
14. Battery indicator
15. MicroSD card reader
16. Headset / Speaker jack
17. USB 3.2 port
18. Kensington lock slot
Operating system1 Windows 11 Home
CPU and chipset 1 AMD Ryzen™ AI 5 340 hexa-core processor
Memory1, 2, 3 Dual-channel LPDDR5X SDRAM support
• 16 GB of onboard LPDDR5X system memory

Display4 16.0″ display with OLED (Organic Light-Emitting
Diode) technology, WUXGA+ 2048 x 1280, high
brightness (400 nits, typical value) Acer
CineCrystal™,
• 16:10 aspect ratio, color gamut DCI-P3
100%(Typical value), support 120Hz, certified by
True Black HDR 500(@HDR 500, brightness reach
500 nits)
• Wide viewing angle up to 170 degrees
• Mercury free, environment friendly

Audio • DTS® Audio, featuring optimized bass response and micro-speaker distortion prevention
• Acer Purified.Voice technology with AI noise reduction in 3 mics array built-in microphones to support Advanced Privacy Mode. Features include far-field pickup,
dynamic noise reduction through neural network, adaptive beam forming, and pre-defined personal and conference call modes.
• High SNR DAC with 2.1 Vrms out capability and can driver high impedance headphone (up to 600 ohm)
• Acer TrueHarmony Technology for lower distortion, wider frequency range, headphone-like audio and powerful sound by Acer Ultra Boost Stereo Speaker Module
• Compatible with Cortana with Voice
• Hi-Res Audio Certification by JAS ( Headphone Output setting supported up to 24bit /192KHz)
Storage1, 5 Solid state drive
• 1 TB, PCIe Gen4, NVMe

Webcam1 Video conferencing
UFC with:
• Narrow USB FHD camera+IR camera with blue glass
• Compatible with Windows only
• 1920 x 1080 resolution
• 1080p HD video at 60 fps with Temporal Noise Reduction
Wireless and
networking1
WLAN
• Intel® Wi-Fi 6E Wireless LAN
• 802.11 a/b/g/n/ac/ax
• Band: 2.4 GHz, 5 GHz, and 6 GHz
• 2×2 MIMO technology
WPAN
• Supports Bluetooth® 5.3 or above
Dimensions and
weight6.7
Dimensions: 354.9 (W) x 250.1 (D) x /15.9 (H) mm (13.97 x 9.85 x /0.63 inches)
Weight: 1.55 kg (3.42 lbs.) with 4-cell battery pack, OLED WUXGA display
1.57 kg (3.46 lbs.) with 4-cell battery pack, WUXGA display
Power adapter and
battery8.9
Power adapter
3-pin 100 W PD PCR 50%, TCO 9.0 AC adapter
Battery:
65 Wh 4-cell Li-ion battery
For models with WUXGA Panel + SSD
Battery life:
Up to 12.5 hours (based on MobileMark® 2025 test results)
Up to 14.5 hours (based on video playback test results)

Input and control Keyboard
99-/100-/103-key Acer backlight keyboard layout with numberpad and
multiple international language support, SR05P
Touchpad
Multi-gesture touchpad, supporting two-finger scroll; pinch; gestures to open
Cortana, Action Center, multitasking; application commands
• Microsoft Precision Touchpad certification
• Moisture resistant
Control Keys
• Programmable key – my key
• Acer Sense Key
• Copilot Key
Windows Desktop
Apps11
Acer LiveArt
Acer QuickPanel

Warranty One-year International Travelers Warranty (ITW)
1. Specifications vary depending on model.
2. Shared system memory may be allocated to support graphics, depending on system memory size and other factors. Actual system m emory available to the operating system will be reduced by any memory used by the graphics solution and resources
required by the operating environment.
3. Memory speed may vary, depending on the CPU, chipset or memory fitted.
4. All brands and product names mentioned herein include trademarks of their respective companies and are used solely to describe or identify the products.
5. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating enviro nment. Acer Recovery Management uses a portion of the stated hard disk capacity as dedicated backup space.
6. Minor variations in system dimensions are possible due to the manufacturing process .
7. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
8. Listed battery life is based on testing using video playback. The test clip loops and continues to run, without interruption or any other inputs, until the battery is drained. Stated battery life is for comparison purpose only. Actual battery life va ries by
model, configuration, applications, video chip format and features used. A battery’s maximum capacity decreases with time and use. Battery life test configuration: AMD Ryzen™ AI 5 340, AMD Radeon™ Graphics, WUXGA, SSD only, 16GB of LPDDR5X
memory. Battery life test condition: LCD brightness 150 nits, connected headphones, WLAN off, Bluetooth off and Better Battery Mode on.
9. Listed battery life is based on testing using Web browsing. The test clip loops the loading of 50 selected websites using Mic rosoft Edge every 30 seconds, until the battery is drained. Stated battery life is for comparison purpose only. Actual batter y life
varies by model, configuration, applications, video chip format and features used. A battery’s maximum capacity decreases with time and use. Battery life test configuration: AMD Ryze n™ AI 5 340, AMD Radeon™ Graphics, WUXGA, SSD only, 16GB of
LPDDR5X memory. Battery life test condition: 100 nits LCD brightness, 50% speaker volume, WLAN on, Bluetooth on, no WW direct Internet connection.
10. Actual battery life may vary considerably by specifications, depending on product model, configuration, applications, power m anagement settings, operating conditions, and features utilized. Performance variation also arises based on components in
use, which includes but is not limited to the processor, RAM capacity, storage, display and resolution, etc.
11. Bundled software may vary depending on hardware configuration, OS and regional availability.
Note: This specification is based on Aspire A16-61M Specifications (v1-0-1)
